Features
-
Premium-grade aluminum with an anodized or electrostatic powder-coated surface finish, delivering a highly sophisticated and premium texture.
-
Equipped with imported LED chips, featuring minimal light depreciation (excellent lumen maintenance), an extended lifespan, and high lumen output.
-
Optical-grade PC lens ensures high light transmittance and prevents fogging/yellowing over time.
-
The mask utilizing imported PMMA material and light diffusion technology offers superior light transmittance and excellent corrosion resistance.
-
Delivers soft and refined light with seamless jointing (connection) capabilities, supporting precise control via DMX512 technology.
Parameters
| Color Temperature | Single color/RGB/RGBW |
| Rated Power | 10W/12W/14W |
| Led Quantity | 48 |
| Led Light Source | 5050/2835 |
| Input Voltage | 24V |
| IEC | Safety Level III |
| Anti-glare baffle optional | No |
| lens Angle | 120° |
| Optical Lens | PC |
| Average Lifespan | 50000 hour |
| Control Method | normally on/DMX512 |
| Pixels | 8 |
| Rated Current | 0.4-0.58A |
| Power Factor | \ |
| Voltage Frequency | \ |
| 1 way max long distance | 8pixels |
| Connector Type | M12 |
| Initial Liminous Flux | 256.6lm |
| CRI | 83.43 |
| Luminous Efficiency | 22lm/w |
| Appearance Color | Sand gray |
| Working Temperature | -30℃~55℃ |
| Working Humidity | 0%~100% |
| IP Rating | IP66 |
| Protection Type | Glue |
| Weight | 0.68kg/m |
| Material of Fixture | 6063streched alluminum |
| Cover Material | PMMA |
| Length(mm) | 1000mm |
| Width(mm) | 20mm |
| Height(mm) | 56mm |
