Features

  • Imported PC mask (cover) features high light transmittance, with superior resistance to yellowing and cracking.

  • Versatile mounting structural design allows for multiple installation options, ensuring effortless installation and maintenance.

  • Equipped with imported LED chips, featuring an extended lifespan, high lumen output, and minimal light depreciation.

  • Supports precise control via DMX512 digital signal technology.

  • Can be paired with matching aluminum profiles/tracks to make installation even more convenient.

Parameters

Color Temperature Single color/RGB/RGBW
Rated Power 1.2W/2.4W
Led Quantity 6
Led Light Source 2835/3535
Input Voltage DC24V
IEC Safety Level III
Anti-glare baffle optional No
lens Angle 120°
Optical Lens \
Average Lifespan 50000 hour
Control Method Normally on/DMX512
Pixels 1

Rated Current 50-100mA
Power Factor \
Voltage Frequency \
1 way max long distance 120pixels
Connector Type M12

Initial Liminous Flux 104lm
CRI 80
Luminous Efficiency ≈87.4lm/w

Appearance Color Black
Working Temperature -30℃~55℃
Working Humidity 0%~100%
IP Rating IP66
Protection Type Glue

Weight 35g/pcs
Material of Fixture PC
Cover Material PC
Length(mm) 52.5mm
Width(mm) 44.7mm
Height(mm) 22.7mm
